Tube Amp Maintenance & Handling Tips

March 28, 2014 by · 1 Comment

Guitar Amplifier ExplodesTo get the most out of your tube amp, which can be a hefty investment, here are some easy to follow handling and maintenance tips. There’s no arguing that tube amps still set the standard for tone – modern solid state and digital amps merely emulate the tube amps of the past. The unfortunate drawback however, is that tube amps are more expensive and fragile compared to solid state alternatives. Repairs and maintenance add to the already high costs of tube amps. Thankfully, some of these extra expenses can be avoided with proper care and maintenance. Read more

Understanding Class A and Class A/B Guitar Amplifiers

April 30, 2013 by · Leave a Comment

playing the guitarMany people are not familiar with the difference between class A and class A/B circuits, even tough it has a huge effect on an amplifier’s tone. The basic answer is this: These two classes of amplification illustrate two different types of output tube (or power amp tube, as some people like to call them) wiring. Read more

Field Guide to Guitar Amplifier Tubes – Everything You Need To Know

March 27, 2013 by · 3 Comments

Guitar amplifier valve tubesWhat is a vacuum tube? — If the link between a light bulb and a raging Marshall stack doesn’t seem obvious, take a glance at those vacuum tubes glowing inside your amp. And then pay your respects to Thomas Edison, the Wizard of Menlo Park, New Jersey.

Edison produced an incandescent light bulb in the late 1870s by feeding an electric current to a filament until it burned bright red. He then sheathed the filament in a glass bulb and extracted the oxygen, thus creating a vacuum to prevent the filament from burning up.

During further experiments in 1883, Edison detected electrons flowing from the filament, through the vacuum and over to a metal plate he had placed inside the bulb. This discovery, named the Edison Effect, remained a minor phenomenon until another scientist, John Fleming, found that these electrons could be used to detect radio waves and convert them into electricity. Fleming added a second metal element to the bulb, thereby creating the first diode, or—to use a name more familiar to guitarists—rectifier. In 1906, inventor Lee de Forest added a third element to the bulb and found that the resulting triode could be used as both a switch and an amplifier. Today, the vacuum tube has evolved to include a complex assembly of plates, grids and heating elements that produce a more efficient part. Read more

Fight Club: Big Amps vs. Little Amps

January 12, 2013 by · 4 Comments

Mesa Boogie Transatlantic TA-15There seems to be an awful lot of interest these days in tube amps that put out lower amounts of power, especially in more boutique, cork-sniffing circles. Just about every amp company has some kind of lunchbox-sized head or ankle-biter combo that puts out five to fifteen watts of power, it appears, and many players are taking the bait and paying top bucks for these little guys. Devotees of these things claim that “five watts is plenty to gig with” and they are more than able to hang with a drummer. Personally, I have a hard time with that statement. Read more

Tube vs Solid State Amplifiers – Which is Better?

January 9, 2013 by · 5 Comments

Tube Amps vs. Solid State AmpsThere are a few central debates that continually rage in this thing of ours, topics that never seem to get exhausted during online forum or real time arguing: Gibson vs. Fender, Fender vs. Marshall, Ginger vs. Mary Ann, Bud vs. Miller, and, most importantly, tube amps vs. solid state amps. These are the things guitarists think about. Now, I can’t help you decide to play a Les Paul over a Strat or who to spend Read more

Electric Guitar Pickups 101

December 1, 2011 by · Leave a Comment

How electric guitar pickups workAn electric guitar’s sound is deeply influenced by its pickups. For a musician who has little or no knowledge of electronics the matter can often seem to be incredibly complicated. When it comes to electronics in general, pickups are quite easy to wrap your brain around. This article will explain the connection between the electronics and sound. Read more

How to Listen to and Care for Your Amp When It’s Sick

November 3, 2011 by · Leave a Comment

Fender Vibro KingGuitar amps are, no matter how you cut it, black boxes. You may think you have control over them, but when it gets down to it, you can’t really see inside the black box, and even if you could, there aren’t any moving parts. Electricity is largely non-mechanical. Or in other words, magic. And when the magic stops, most people think all they can do is resort to prayer. Or an amp technician.

When your amp isn’t performing up to snuff, there’s still a lot you can do without having an EE degree, or even knowing how to operate test equipment. Here are some holistic approaches—and solutions—you can try yourself, as I did when my tube amp went on the fritz. Warning: Some of the following procedures involve messing around with the components of the amp, so be careful. Electricity can kill you. Proceed at your own risk. Read more

Basic Electric Guitar Circuits: Potentiometers and Tone Capacitors

September 15, 2011 by · Leave a Comment

What is a Potentiometer?

Potentiometers, or “pots” for short, are used for volume and tone control in electric guitars.  They allow us to alter the electrical resistance in a circuit at the turn of a knob.

Potentiometers and Tone Capacitors

It’s useful to know the fundamental relationship between voltage, current and resistance known as Ohm’s Law when understanding how electric guitar circuits work.  The guitar pickups provide the voltage and current source, while the potentiometers provide the resistance.  From Ohm’s Law we can see how increasing resistance decreases the flow of current through a circuit, while decreasing the resistance increases the current flow.  If two circuit paths are provided from a common voltage source, more current will flow through the path of least resistance.
Potentiometers and Tone Capacitors

We can visualize the operation of a potentiometer from the drawing above.  Imagine a resistive track connected from terminal 1 to 3 of the pot.  Terminal 2 is connected to a wiper that sweeps along the resistive track when the potentiometer shaft is rotated from 0° to 300°.  This changes the resistance from terminals 1 to 2 and 2 to 3 simultaneously, while the resistance from terminal 1 to 3 remains the same.  As the resistance from terminal 1 to 2 increases, the resistance from terminal 2 to 3 decreases, and vice-versa.

Tone Control:  Variable Resistors & Tone Capacitors

Tone pots are connected using only terminals 1 and 2 for use as a variable resistor whose resistance increases with a clockwise shaft rotation.  The tone pot works in conjunction with the tone capacitor (“cap”) to serve as an adjustable high frequency drain for the signal produced by the pickups.  The tone pot’s resistance is the same for all signal frequencies; however, the capacitor has AC impedance which varies depending on both the signal frequency and the value of capacitance as shown in the equation below.  High frequencies see less impedance from the same capacitor than low frequencies.  The table below shows impedance calculations for three of the most common tone cap values at a low frequency (100 Hz) and a high frequency (5 kHz).

Potentiometers and Tone Capacitors

When the tone pot is set to its maximum resistance (e.g. 250k?), all of the frequencies (low and high) have a relatively high path of resistance to ground.  As we reduce the resistance of the tone pot to 0?, the impedance of the capacitor has more of an impact and we gradually lose more high frequencies to ground through the tone circuit.  If we use a higher value capacitor, we lose more high frequencies and get a darker, fatter sound than if we use a lower value.

Volume Control:  Variable Voltage Dividers

Volume pots are connected using all three terminals in a way that provides a variable voltage divider for the signal from the pickups.  The voltage produced by the pickups (input voltage) is connected between the volume pot terminals 1 and 3, while the guitar’s output jack (output voltage) is connected between terminals 1 and 2.  From the voltage divider equation below we can see that if R1 is 0? and R2 is 250k?, then the output voltage will be equal to the input voltage (full volume).  If R1 is 250k? and R2 is 0?, then the output voltage will be zero (no sound).

Potentiometers and Tone Capacitors

Potentiometer Taper

The taper of a potentiometer indicates how the output to input voltage ratio will change with respect to the shaft rotation.  The two taper curves below are examples of the two most common guitar pot tapers as they would be seen on a manufacturer’s data sheet.  The rotational travel refers to turning the potentiometer shaft clockwise from 0° to 300° as in the previous visual representation drawing.
Potentiometers and Tone Capacitors

How do you know when to use an audio or linear taper pot?

It’s really a matter of personal taste when it comes to volume control.  Notice how the rate of change is much more dramatic on the audio taper pot when traveling back from 100% to 50% rotation.  This means that the same amount of rotation would give you a more intense volume swell effect with an audio taper than with a linear taper.  Using a linear taper volume pot would give you a more gradual change in volume which might feel like you have more fine control with which to ease back the volume level.

For tone control, it’s basically standard practice to use an audio taper.  The effect of the tone circuit is not very noticeable until the resistance gets pretty low and you can get there quicker with an audio taper.

How do you know what value of potentiometer to use?

The actual value of the pot itself does not affect the input to output voltage ratio, but it does alter the peak frequency of the pickup.  If you want a brighter sound from your pickups, use a pot with a larger total resistance.  If you want a darker sound, use a smaller total resistance.  In general, 250K pots are used with single-coil pickups and 500K pots are used with humbucking pickups.

Specialized Pots

Potentiometers are used in all types of electronic products so it’s a good idea to look for potentiometers specifically designed to be used in electric guitars.  If you do a lot of volume swells, you’ll want to make sure the rotational torque of the shaft feels good to you and most pots designed specifically for guitar will have taken this into account.  When you start looking for guitar specific pots, you’ll also find specialty pots like push-pull pots, no-load pots and blend pots which are all great for getting creative and customizing your guitar once you understand how basic electric guitar circuits work.
