Jensen Jet Series Electric Lightning JC12-70EL Speaker

January 14, 2012 by · Leave a Comment

guitar speakersJensen speakers were the original speaker used in guitar amplifiers back in the day, and they are prized and revered for the ultimate vintage tone they produce. Jensen used Alnico magnets in these speakers and players grew to love the way they responded to their personal touch and playing style. These days, players have many choices when it comes to the type of speakers they put in their amps and old-school vintage is merely one option Read more

Jensen Jet Falcon 10” Instrument Speaker

January 3, 2011 by · Leave a Comment

Jensen Jet Falcon 10” Instrument SpeakerJensen Musical Instrument Speakers is pleased to announce the latest addition to the Jensen Jet series, the 10-inch Falcon. With its 40 watts of power, a ceramic magnet, and a seamed green cone made from all natural materials, the 10-inch Falcon is specially designed to ensure optimum tone for all styles of music.

Musician's Friend

The Falcon 10-inch tone is warm and straightforward with a pronounced low end. Its mid frequencies are slightly enhanced over the Falcon 12-inch, and it has a very sweet, yet cutting, high end. When presented with overdrive distortion it creates some mean fuzz.

This new Jensen speaker once again demonstrates Jensen’s tradition of giving players what they are asking for in tone. Watch for more Jensen Jet series speaker designs on the horizon.
jensentone.com

Jensen Jet Falcon Guitar Speakers

Guitar Amps 101 – Speakers: Does Size Really Matter?

June 3, 2009 by · Leave a Comment

DrZ stingray guitar ampMany different types of speakers have been used over the years to amplify electric guitars. The most common are speakers with 10-inch and 12-inch measurements. Generally speaking (pun intended), a smaller speaker produces more top end, or treble, than a larger one. Thus, an amp outfitted with 10’s usually has a brighter, tighter sound and the same amp with 12’s will be darker sounding. Read more

Mackie, Event And Hafler Powered Studio Monitors

October 2, 2008 by · Leave a Comment

Recording studio Mackie Event Hafler monitorsChoosing monitor speakers is probably the most subjective part of equipping a recording studio. Specs and features inform you of the manufacture’s intent, but only your own ears can tell you how a given set of speakers suits your taste, sensitivity and listening environment. We tested three models of powered studio monitors—speakers with built-in power amps, so you can run signal directly to them from your mixer.

MACKIE HR824
Mackie designs’ HR824 High Resolution Studio Monitors feed 150 watts to an 8.75-inch woofer and 100 watts to a one-inch, aluminum allow domed tweeter, housed in a cabinet measuring 15.75 x 10 x 12.2 inches.

Reported frequency response is 39 Hz 20 kHz (+/- 1.5 dB). Instead of a conventional bass port, these speakers feature a “passive radiator” to dish out low frequencies. Bass handling was impressive, especially the way the speakers distinguished between low midrange and deep sub-bass. The high end was bright, but no harsh; details like hi-hat cut clearly without inducing ear fatigue. Even better, the HR824s separated true highs frim upper mids without noticeable smearing.

The HR824s offer impressive imaging. Sit anywhere near the sweet spot and you’re treated to a three-dimensional soundstage, where the music seems to float in space. Conversely, in our tests, frequency response was affected by shifts in listening position.

Setup was quite simple. The speakers have a number of user friendly controls, including clearly illustrated rear-mounted switches designed to optimize the speakers for various room locations, as input sensitivity pot and switches for low and high cut.

The End Line

Pumping everything from Jazz to Jungle, the versatile HR824s never broke sweat. Mackie fans will not be disappointed.

EVENT 20/20
The Event 20/20 bass Biamplified Monitor System was the smallest of the speakers we tested: just 10.25 x 14.75 x 11.75 inches. The enclosures’ bass ports are on the front, allowing you to mount the speakers against the wall if desired. The biamped system pushes 130 watts to the eight-inch low frequency driver and 70 watts to the one-inch silk domed tweeter. Controls include continuously variable input sensitivity, high and low frequency trim (+/- 3 dB), circuit breaker reset and power, all on the cabinet’s back. The single input accepts both XLR and ¼-inch plugs.

Event’s literature promises sonic size disproportionate to the speaker’s physical dimensions, and they’re not just blowin’ smoke. The 20/20’s imaging is impressively deep and live sounding, with a wide sweet spot. Reported frequency response is 38 Hz-20 kHz (+/- 2 dB). In listening tests, bass response was fast and snappy under normal circumstances. Highs sounded detailed but smooth on “warm” program material like Jazz; more aggressive music was ever-so-slightly strident until we rolled the highs back a dB or two.

The End Line

The Event 20/20 sound sweet at low volumes, and cranking these solid performers makes ‘em sound positively huge.

Advertisement————————————
————————————————————

HAFLER TRM8
The TMR8 are the first speakers built by Hafler, a company with an impressive history of amp building. Powered by “trans-nova” technology, the bi-amped system feeds 150 watts to the eight-inch Polypropylene cone woofer and 75 watts to the one-inch soft dome tweeter. Those in tight quarters take note: to prevent boundary loading the woofer, Hafler tells you to mount the vented enclosure (10.25 x 15.44 x 13 inches) at least five inches from any walls.

DIP switches, including bass and treble boost/cut (+/- 4 dB) and input sensitivity controls, as well as RCA, ¼-inch and XLR inputs are provided on the back panel. The power switch is on the front.

The TMR8s, with a reported frequency response of 45 Hz-21 kHz (+/- 2 dB), really kicked bass. Treble response was sharp and detailed—especially nice at low volumes, but a bit fatiguing when cranked up. The Haflers did an especially nice job of reproducing detailed percussive sounds and lent detail to “warm” program material like Jazz.

Individual panning could be heard distinctly, but the image seemed somewhat tow-dimensional outside a fairly narrow sweet spot. That said, overall frequency response fared quite well outside the sweet spot, a real plus if you move around your studio during sessions.

The End Line

Those who crave pounding bass and a bright high end will find the TMR8s just the right blend of aggression and precision.

Gear-Vault Classifieds is an eBay alternative. Come sell your music equipment with us, for free!

Understanding Speaker Cabinet Designs

September 23, 2008 by · Leave a Comment

guitar cabinet factory 4x12Lesson #1

Ask a group of guitarists what their favorite instrument, amplifiers and effects are, and each one will surely ramble on for hours about his gear of choice. Ask that same group about their favorite speakers and cabinets, however, and many of them will likely respond with a simple “I dunno.” The sad truth is that even though cabinets and speakers play major roles in shaping the tone of a guitar sound, they are often overlooked by players.

The overall sound of a cabinet is the result of all the components that go into building it and how they’re put together. Once you acquire the knowledge of what goes into building speakers and cabinets, you’ll start to understand exactly what you like and dislike about different cabinets. In this lesson, I’m going to focus on defining the components and materials that go into building speakers and cabinets as they relate to the sound they produce. My hope is that at the end of the two lessons, you will be well informed and on your way to identifying what you preferences are and what speakers and cabinets complement your playing the best.

With very few exceptions, cabinets are made out of wood. Plied birch wood is far and away the most common choice, though some cabs are made from particle board or a combination of the two. Sonically, birch is great because it strikes a very desirable balance; it’s rigid enough to produce punch and definition while being soft enough to sound warm but not floppy. Remember that the cabinet acts as a resonator for the speakers just as the wood of a guitar acts as a resonator for the vibrations of the strings. Birch is also super durable and is well suited to withstand the vibrations, abuse and travel that a cabinet is likely to endure. Read more

Jenson P10R Speaker Review

August 23, 2008 by · 3 Comments

Jensen P10R vintage SpeakerIf one of your guitar-playing buddies walks up to you and says, “I’ve got the blues,” it could mean one of three things: he just found out his girlfriend’s nick-name is “Back Door Bertha,” he’s a drug pusher or he just had some Jensen P10R speakers installed in his amp. Known as the “blue cap,” “blue bell” or “blue frame,” the original Jensen P10R is considered the ultimate guitar speaker by many tone connoisseurs, and with good reason.

Read more
